ITS

Intelligent Testing Station from R-SS is an integrated application for acquisition, storage, transmission,
analyzing of data, for natural gas, hazardous liquids and other common pipeline systems. Both DC and
AC voltage can be acquired, including stray current, polarized potential and natural potential which can be monitored.

Terminal Standard Features

Range of potential: -3,000 mV ~ 3,000 mV

DC Voltage Acquisition Error: less than 0.01V

AC Interference Voltage Acquisition Range: 0~80V

AC Voltage Sampling Error: less than 1%

RTC Clock Error: less than 10 seconds per year

Transfer Interface: RS-485/GPRS/Ethernet/Satellite

Monitoring: parameters of rectifier, state of pipeline;

Life of Battery: Min. 20days ~ Max. 2Years (Depends on sampling rate)

History Data Storage: Min. 20days ~ Max. 2Years (Depends on sampling rate)

Power of Controller: DC 5V input or battery input;

Storage Capacity: 24Mb, more than 4G if SD card can be used

Input Impedance: > 1M

DC Input Anti-Interference: more than AC30V

Protect Degree: IP66

PCB Treatment: moisture proof, mould proof and salt proof


Server Standard Features

The server is C/S struction, and acquires data through TCP/IP mode, the system supports the internet,
if you have public IP, you can get data fluently, and SMS report is another way to transfer your data.

Server Database: SQLSever2000

Server’s Monitor: resolution support 1440 x 900

Server can set parameters of data acquisition terminals, and monitor the communication

Friendly UI to show dynamic cathodic protection situation of pipeline

Support setting GPRS terminal address, channel, send interval etc.

Real-time graphics display

Save data from the terminals

Graphical alarm and message alarm

Print various types of statistical table
