Analog Thyristor Transformer Rectifier

ATTR


ATTR Introduction

Analog Thyristor Transformer Rectifier adopts analog circuit scheme. It is very stable,
strong anti-interference, =and easy to operate, so the e
quipment is suitable for the
hazard environment.R-SS provides Analog Thyristor Transformer Rectifier in
every standard configura
tion, including air-cooled, oil cooled andexplosion proof.
All the enclosures can achieve IP65 grade. The rectifiers are available in almost
any voltage and current output, and can be monitored by point-to-point communication method.


Standard Features

Single or 3-phase input

Plinth mounted

Dry powder coated enclosure

Fully magnetic circuit breaker

Stepless adjustment

A.C. and D.C. lightning arrestors

Constant current mode, accuracy ≤±1%

Constant potential precision, ≤5mV

Constant potential mode, protection potential range - 3000 mv~ + 3000 mv

Heavy duty transformer with 20% over design capacity

Interrupter mode, time variable

DC output volt ,amp and potential meters, with +/- 1.5% accuracy

Ripple: 3 phase, ≤5%, single phase, ≤10%

Transformer: min. 95% efficient, Class “F” rated

When the output current or output voltage exceed 100%-110% of rated value,
current down to zero and the fault light on.

Lack phase alarm

temperature high alarm

over/under potential limited alarm

IP65, NEMA4x

4~20mA transmitter

Time-elapse recorder

Sunshade, outdoor normally provided.
